CFD-BJ-6 AUTOMATIC FILLING AND SEALING MACHINE

Category:

Eight treasure porridge filling and sealing machine

Summary:

The machine with high speed, top technology level, new design, all the systems are automatic such as bowl(cups) feeding, rice filling, jujube filling, gingko filling, liquid filling, film putting, date printing, sealing, photocell checking, cutting and cup drop out. We can make the machine increase or decrease any function according to your requirement such as the cover add with stainless steel and glasses, CIP, PLC, cup drop out system by manipulator…etc. The machine is made of acid proof stainless steel, speed controlled by transducer. The temperature control system are using the Solid State Relay with top brand temperature meter, retrench power, temperature control with high stabilization, sealing with best quality, appease for high temperature sterilize within 121degree.

Mobile:

+86-13802715588

Related products

Messages

Details

产品特点

Features

We can make the machine increase or decrease any function according to your requirement such as the cover add with stainless steel and glasses, CIP, PLC, cup drop out system by manipulator…etc.

The machine is made of acid proof stainless steel, speed controlled by transducer.

The temperature control system are using the Solid State Relay with top brand temperature meter, retrench power, temperature control with high stabilization, sealing with best quality, appease for high emperature sterilize within 121degree.

主要技术参数

MAIN TECHNICAL DATA

生产量output	8500pcheng
容量 filling capacity	100-350ml
使用电源power supply	380V 50Hz
耗气量air consumption	0.8㎥/min
整机功率power	9.5KW
整机重量weight	2.2T
外型尺寸size(m)	4.5x1.1x1.8
